01 Hinged Binocular Viewing Head

45° inclination provides optimal ergonomic comfort. The hinged design allows interpupillary adjustment from 53–75 mm, accommodating different users with ease.

02 Wide-Field High Eye-Point Eyepieces

22 mm wide-field eyepieces deliver a flat, expansive field of view, reducing eye fatigue during prolonged use. High eye-point design enables observation while wearing glasses. Adjustable diopters ensure synchronized clarity for both eyes.

03 LED Illumination with Phase Contrast Support

Long-life, high-brightness LED provides stable, uniform, and glare-free illumination. Light intensity is continuously adjustable via a side-mounted knob to maintain optimal image quality. The slide-in phase ring plate enables phase contrast observation.

04 Built-In Side Camera Port

Integrated C-mount interface compatible with mainstream cameras. Positioned on the lower left side for a more rational layout, offering greater operational space for cell observation.

05 Integrated Body Design

Compact, all-in-one construction fits easily into laminar flow cabinets and confined cell rooms. Rear carry handle ensures convenient mobility and transport.

06 Quick-Release Sample Holder

Equipped with a culture dish plate and universal sample clamp to accommodate various dishes. The clamp can be installed or removed independently and quickly, freeing a flat stage surface for special-shaped culture vessels.
